Saturday, August 16, 2014

Did Bakker Get Spinosaurus Right After All?

Roll with me for more Spino madness in my book Dinosaur Enlightenment: Piercing the Veil on Kaiju Dinosaur in an Age of Disruption available on Amazon ebook and soft copy!! https://www.amazon.com/Dinosaur-Enlightenment-Piercing-Kaiju-Disruption/dp/B08M2FZ9GX/ref=tmm_pap_swatch_0?_encoding=UTF8&qid=&sr= *Update 9/23/14 As this post continues to get heavy traffic it should be noted it was first posted (8/16/14) before the official publication of the new Spinosaurus aegyptiacus material (Ibrahim et al., 2014) but I will leave it as it was originally posted. That being said I have seen nothing in the new material, nor the arguments against it I have solicited online, that would disqualify it as one of several terrestrial locomotory styles possible to this animal. Indeed I think based on the ontogenetic stage of the animal as well as the substrate the animal is on many locomotory styles were utilized. This ability to switch locomotory styles is well documented in crocodiles especially with regards to size and substrate. Additionally, as some have objected, what I am proposing is not a radical overhaul of known theropod anatomy but simply a co-option of known theropod resting anatomy. As such, belly sliding - which is utilized by several amphibious/aquatic  members of both extant archosaur lineages (birds/crocs)  - with possible use of the forelimbs in a "combat crawl" motion still remains a viable, and in my opinion robust, hypothesis for terrestrial locomotion in this animal.

We all know and love the new Spinosaurus aegyptiacus reconstruction right? "Disenchanting" is how Douglas Henderson described it on facebook. And it does fall a little bit shy of the impressive dual land/water arch predator it has so often been posited to be, especially since a little movie came out (JP3 duh) and our friend the Spino terrorized everything from T-rex to estranged parents. Truth be told it looks a little clunky, a little too front heavy to work right - at least the way we expect theropods to work  since GSP started drawing them as svelte athletes rip roaring across the page. So, yeah I do want to comment on the new Spino reconstruction and yeah there are a lot of people - very knowledgeable ones at that - that would definitely disapprove of what I am going to do before publication of the new material. But I will argue that my interpretation on what was going on with Spino is in fact presaged by what we already know from other members of spinosauridae and yes, as suggested by the title, I think Bakker got the jump on all of us by suggesting way back when that Spinosaurus was a lot more aquatic than generally portrayed. But I will offer my little Antediluvian Salad spin on Spinosaurus and hopefully you find it interesting. And leave a comment.


Moss Landing/Elkhorn Slough US Army Corps. public domain
Before I get to Spino itself I want to tell a little story to help illuminate my point. A little tale about kayaking. I do like to kayak and one of the funner places to do so in California is a place called Elkhorn Slough in the Monterey Bay. It is a tidally influenced estuary and there is always open access to the ocean, especially because of the harbor at the entrance having to be maintained. It is noted for the unique population of sea otters that forage in an estuary as opposed to the ocean - often times within view of the highway that crosses the estuary. These estuarine sea otters have been shown to predate heavily on crabs and, in a classic trophic cascade, have bolstered stands of eel grass in the estuary. In addition to the otters, there are loads of harbor seal, water birds and miles of watery inlets to explore. It is the type of place that lets you imagine the California that once was - when coastal lagoons and estuaries dotted the entire coast, flocks of birds blackened the skies and grizzlies patrolled everywhere. Elkhorn Slough is so spellbinding in fact that as I kayaked it I lost track of the depth of water I was in and became grounded in mud in shallow water. This sucks I thought to myself as I considered the possibility of having to get out and push my kayak back into deeper water. Thankfully cooler heads prevailed. I did not make the rookie mistake of getting out of the kayak where I would have likely got mired waist deep in tidal mud in a sulphurous mess. In our best impersonation of saltwater crocodile plowing through tidal flats we shimmied left and right and paddled with short quick thrusts to get back to deep water. And if you imagine the long rounded body of the kayak as equivalent to the long low body of a crocodile, seal, or otter the analogy of moving through deep/sticky mud in a kayak is spot on. And if you think of large amphibious tetrapods moving through the mud, and I am talking deep/miring mud, they all get low and down in it and use their body surface area to prevent sinking too deep. Go look at saltwater crocodiles steaming through tidal mud flats in Queensland.



Large tetrapods that do not use this technique in deep mud risk getting mired. For large bipeds the risks are even more extreme as all of the weight is concentrated on just one limb when pushing off. As the picture above attests a very large American crocodile has some advantages over a bipedal hominid in deep mud (he survived btw). Whether you are a trained soldier or a simply like to take the Spartan Challenge one is quick to see the benefits of getting down into the mud to get through it. It might seem counter intuitive at first but just ask this guy.


Now following this line of thought of how to traverse muddy areas as a large tetrapods let us revisit Spinosaurus aegyptiacus - especially with respect to the new reconstruction c/o Paul Sereno.

Nat Geo
So we got a couple things going on here. A very long, low body with some ridiculous looking shorty-shorts legs. Especially reconstructed in the Paulian push off mode the beast looks seriously in danger of tipping over. Combined with the strangely down turned head and the heavy arms the question is begged is this manoeuvre even possible? To further complicate the issue let us put this animals in its habitat - tidal/deltaic wetlands. (insert discussion on spinosauridae habitat choice, diet, you can find the evidence is compelling!) Now we have the issue of a massive, bipedal animal in a habitat full of mud - as discussed earlier large bipeds in thick mud can be an issue. What was the poor spino to do? What I am going to suggest is that Spinosaur and its ilk went to boot camp and learned how to combat crawl. Not entirely quadrupedal but not entirely bipedal but a bit of a compromise between the two. Lower the torso, push off with the short back legs - a bit like a penguin actually - and the coup de grace those bizarre and massively boned and muscled forelegs. Simply fold them in the manner all theropods are now known to do. The radius and ulna take the weight and the clawed digits are curled inwards. Take a look at this pic c/o Dave Hone of a Suchomimus arm. Spinosaur arms were robust but not as elongate as often depicted. But when the spino goes into this belly slide I will suggest the arms can assist in kind of a "combat crawl" motion. The elbow is where the movement happens and the radius and ulna take the weight.

Seen in this manner the long low torso, short legs, short but powerful forearms, and downward sloping neck shared by all spinosauridae now start to make sense. Chasing after stuff on terra firma these  animals were not. But if you were in the water, or a hapless dinosaur mired in the mud, spino could get the jump on you.

Duane Nash
Above is a very quick and punk rockish sketch I did yesterday of a spino moving through thick tidal flat mud. The black color on the underside is not some type of reverse countershading but the thick/clingy mud you find in such environments. I have been drawing theropods on and off for over 20 years but drawing spinosaurids you have to sort of unlearn what you are used to. Not tall and gracile, no graceful S-curve to the neck, not a compact torso but a long barrel shaped torso. They seem to go against the "birdy, svelte, uber athletic" theropod bauplan that has dominated reconstructions essentially as a result of Gregory S. Paul's influence. Hence the culture shock at the new reconstruction of Spinosaurus. In hind sight maybe we should have seen this coming. All of the known relatives of Spino tip forward a bit, have short heavy arms, and well just look oddly proportioned compared to other theropods. Spinosaurs took these attributes to the extreme. I would suggest all spinosauridae would utilize belly crawls in muddy situations and perhaps occasionally even on dry land. If you look at the list of large amphibious tetrapods that do not utilize the belly slide in thick mud the list is basically.... nil? Maybe hippos don't belly slide, but they do have four short powerful limbs and a long torso. Capybaras?


Below is a depiction I did of Spino with just the body showing and not obscured in the mud. It is a little difficult to draw as such and work kinematically where everything goes. But I think such a style of movement is a fair compromise considering what we know from these critters anatomically and ecologically.

Duane Nash
And again let us just look at the skeletons of other related spinosaurids. Like I said earlier some take objection to me writing about Spino before the publication but if you look at these skeletons in light of the argument I just put forth for belly sliding/combat crawling there is no reason to say that they may have all been doing it. And I seriously doubt Sereno and Nat Geo are going to suggest this mode of movement because, you know, they put their mount in a Paulian push off extreme cursorial stance. And finally Robert Bakker was suggesting that these guys were a lot more aquatic than generally portrayed. And usually ridiculed for his opinions. Last laugh may go to Bakker on this one.

As for how they moved in the water I think more or less like a hippo but bipedal running underwater. Not tail driven.

Subadult Spino. wiki. legs were likely shorter. Creative Commons Funkmonk
Baronyx walkerii. CC Funkmonk. Note heavy, but short forearms

Above is a skeletal by blogger/artist/researcher Jaime A. Headden. You will notice that of the material we have, the lower legs are missing. Never the less, as in this skeletal, they are usually rendered fairly long and gracile. But they may have been quite a bit stumpier.

Suchomimus tenerensis. CC AStrangerintheAlps
Again with Suchomimus we see that tendency to fall forward a bit. Almost as if it is begging to go belly slide in some primordial ooze.

Suchomimus tenerensis CC Belinda Hankins Miller

Getting low, getting low.





Support me on Patreon.
Like antediluvian salad on facebook.
Watch me on Deviantart @NashD1.Subscribe to my youtube channel Duane Nash.


7 comments:

Andrea Cau said...

PENDING THE OFFICIAL PUBLICATION, this is a plausible explanation of the available information.
I've listed a series of arguments on why Spinosaurus was not "another big theropod" with just a sail. The slender longirostrine snout with retracted naris, the elongate dorsal centra, the very gracile neural spines, suggest an ecology well different from other giant theropods with deep skulls, shortened dorsal centra with taller neural arches and more robust neural spines.
Based on skull and vertebrae morphology alone, I've suggested that Spinosaurus "typical" posture was with a ventrally inclined head, almost touching the ground, suggesting a foraging style different from that of the hypercarnivorous giant theropods. For example, I've suggested that aestivating fish in mud may be among their main food source during the dry season, and that the elongate snout with retraced nares, deep basicranium and reduced sygmoidal neck with powerfull muscular insertion for head rising, and overall axial skeleon geometry are compatible with this feeding adaptation: all these arguments agree with your scenario.

I prefer not to comment on the photo present on NG site, it's too small and - most importantly - it's not clear what is actally known bones, what is hypothetical reconstructed and how many specimens are used for that skeleton.

We have to wait for the actual material. As far as I know, further anatomical details - not visible in the small NG photo - may agree with this interpretation.

Mark Witton said...

Agree with Andrea: spinosaurids were clearly doing something unusual among Theropoda, and it would not be surprising if this extended to locomotor specialities. It's certainly not unreasonable to think a heavy animal adapted to fishing would have some means of dealing with treacherous river substrates.

But - and you know what this 'but' is about - we are getting ahead of ourselves here. The reconstruction offered on the Sereno/NG site is downright weird compared to other spinosaurids, and we - artists and scientists alike - need to know the full skinny before adapting our ideas to it. Ben Creisler, on the Dinosaur Mailing List, has recently mentioned "...some who've seen the forthcoming scientific redescriptions of Spinosaurus have advised caution about the accuracy of new reconstructions". I don't know any details about this, but it's yet another reason to be cautious.

Duane Nash said...

Thanks for commenting guys. I guess getting two cautious comments of "maybe" is about as best as I can hope for in lieu of pending publication. Yes like a kid who can't wait for christmas...

Andrea interesting you mentioned Spinosaurus pillaging aestivating fish during the dry season. I drew a picture depicting such an activity way back in 97/98 of a Baryonyx going after aestivating lungfish. As you can see pretty much see a very dated look for spinosaurs; http://antediluviansalad.blogspot.com/2014/08/a-very-dated-picture-of-spinosaurus.html

Andrea Cau said...

Mark, I am among those that know some detail of the forthcoming Spinosaurus study BUT cannot say anything.
We all have to wait for the paper(s).

Sean McCabe said...
This comment has been removed by the author.
Sean McCabe said...

Interesting for sure. Of course I agree with Mark, but if this is based on proper reconstructions, this does seem sound. I'll add my voice to the bandwagon of "they were doing somewhat weird". Although I seem to remember Scott
Hartman and Jaime Headden both mentioning something about a reconstruction with the sail reaching back to the end of the tail - that seems to be highly different here, with a comparatively restricted sail.

Any idea how fast one of these things could've gotten in that posture? Even if in short bursts. Given crocodiles can have notably fast bursts for a few seconds when they need to.

Duane Nash said...

Thanks for commenting Sean.

I am of the notion that such a posture may have been adopted when covering slippery/muddy terrain and maybe even on solid ground occasionally if the terrain was flat or maybe even too uneven. Perhaps when negotiating turns or in difficult terrain spino would occasionally touch down for better stability. And I make the comparison to penguins again - sometimes they might rock hop, sometimes they walk bipedally, and sometimes they belly slide.

As for how fast they could have got going in this posture? On slippery substrates like mud or sand I think they could have got a good head of steam going - especially if they were going down a sloped bank as crocs often do. Probably in short bursts though. I certainly would not want to test their speed in such environments!!

Semiaquatic animals are interesting because there are so many examples to look at. What is hard to parcel out from extinct animals is trying to place where on the spectrum they fall: primarily aquatic with some ability on land or primarily terrestrial with some aquatic capabilities. But generally I think an animal is going to fall into one of the two camps of being either more terrestrial or more aquatic.

A true master of both domains? Something that is exceptionally quick in both the water and land I don't see happening. Aquatic animals will always be pushed to develop stouter and stronger limbs- which goes contrary to being a good cursorial animal.

If there is some truth to this reconstruction Spinosaurus may have been trending into an increasingly aquatic adaptation.
